X5 AC Drive User’s Manual X5 Parameter Summary Table
DPD00089A - iv - © 2009 Vacon Incorporated All Rights Reserved
207 Vin1 Span 10.0% to 200.0% 100.00% 77
208 Cin Config text string 0-20mA 50 77
209 Cin Offset 0.0% to 100.0% 0.0% 77
210 Cin Span 10.0% to 200.0% 100.0% 78
211 Vin2 Config text string 0-10V 78
212 Vin2 Offset 0.0% to 100.0 % 0.00% 78
213 Vin2 Span 10.0% to 200.0% 100.00% 78
214 Vin1 Filter Time 0 to 1000 ms 20 ms 78
215 Cin Filter Time 0 to 1000 ms 20 ms 78
216 Vin2 Filter Time 0 to 1000 ms 20 ms 78
217 Trim Ref Enable (Set k-Factor) text string 0 78
218 Trim % Factor -100.0 - 100.0% 0.0% 79
222 Ref Loss Config text string No Fault 79
301 Min Frequency 0.0 - Max Freq. 0.0 Hz 79
302 Max Frequency 20.0 - 400.0 Hz 60.0 Hz 79
303 Preset Freq 1 Min Freq-Max Freq 5.0 Hz 79
304 Preset Freq 2 Min Freq-Max Freq 10.0 Hz 79
305 Preset Freq 3 Min Freq-Max Freq 20.0 Hz 79
306 Preset Freq 4 Min Freq-Max Freq 30.0 Hz 79
307 Preset Freq 5 Min Freq-Max Freq 40.0 Hz 79
308 Preset Freq 6 Min Freq-Max Freq 50.0 Hz 79
309 Cut-off Freq 0.0 - 5.0 Hz 0.0 Hz 79
310 Preset Freq 7 Min Freq-Max Freq 60.0 Hz 79
311 Preset Freq 8 Min Freq-Max Freq 0.0 Hz 79
312 Preset Freq 9 Min Freq-Max Freq 2.5 Hz 79
313 Preset Freq 10 Min Freq-Max Freq 7.5 Hz 79
314 Preset Freq 11 Min Freq-Max Freq 15.0 Hz 79
315 Preset Freq 12 Min Freq-Max Freq 25.0 Hz 79
316 Preset Freq 13 Min Freq-Max Freq 35.0 Hz 79
317 Preset Freq 14 Min Freq-Max Freq 45.0 Hz 79
318 Preset Freq 15 Min Freq-Max Freq 55.0 Hz 79
380 Keeper Input Cfg text string 4 (disabled) 79
381 Keeper Max Scale 0-32000 1000 80
382 Keeper Save Time 00:00 - 23:59 0:00 80
384 Keeper Save Rate text string 0 (24 hour) 80
385 Keeper Input Value 0-32000 Read-only 80
386 Keeper Time Rate text string 1 (minute) 80
387 Keeper Rec. Num 0-255 Read-only 80
388 Active Kpr. Record 0-255 Read-only 80
389 Keeper Units text string 1 (GPM) 81
401 Ramp Select text string ART-DI 81
402 Accel Time 1 0.1-3200.0 sec 5.0 sec 81
403 Decel Time 1 0.1-3200.0 sec 5.0 sec 81
404 Accel Time 2 0.1-3200.0 sec 3.0 sec 82
405 Decel Time 2 0.1-3200.0 sec 3.0 sec 82
406 DC Inject Config text string DC at Stop 82
407 DC Inject Time 0.0-5.0 sec 0.2 sec 82
408 DC Inject Level 0.0% to 100.0% 50.0% 82
409 DC Inj Freq 0.0 to 20.0 Hz 0.0 Hz 82
410 DB Config text string Internal 83
414 S Ramp Rounding 1 - 100% 25% 83
No. Parameter Name Options Default User Setting See Page
= cannot change in Run
Bold type = Level 1 parameter
Note that all parameters can be addressed by adding 40000 to the parameter number. For example, parameter 201 (Input Mode) can be
addressed by Modbus address 40201.
