Vacon X5 User Manual

X5 AC Drive User’s Manual X5 Parameter Summary Table
DPD00089A - iii - © 2009 Vacon Incorporated All Rights Reserved
Summary of X5 Parameters
No. Parameter Name Options Default User Setting See Page
001 Model Number Model dependent Read-only 71
002 Software Rev 0.00-99.99 Read-only 71
003 Rated Current 0.0-200.0 A Read-only 71
005 Serial No. 1 0-65535 Read-only 71
006 Serial No. 2 0-65535 Read-only 71
007 USB Soft. Rev 0.00 - 99.99 Read-only 71
008 Option Installed text string Read-only 71
009 Fbus Soft. Rev 0.00 - 99.99 Read-only 71
030 Pwr Down Date dd/mm/yy Read-only 71
031 Pwr Down Time Dd/hh/mm (Dd = Tu, Th, etc.) Read-only 72
102 Output Freq 0.0-400.0 Hz Read-only 72
103 Output Voltage 0-600 V Read-only 72
104 Output Current 0.0-200.0 A Read-only 72
105 Drive Load -200.0-200.0% Read-only 72
106 Load Torque -200.0-200.0% Read-only 72
107 Drive Temp -20.0-200.0 °C Read-only 72
108 Total Run Time 0.0-6553.5 h Read-only 72
109 Power On Hours 0-65535 h Read-only 72
110 Stator Freq 0.0-400.0 Hz Read-only 72
111 DC Bus Voltage 0 - 1000 Vdc Read-only 72
115 Drive Power Out 0.0-200.0% Read-only 72
116 Out Power (kW) 0.0 - 327.67 Read-only 72
117 MWh Meter 0 - 32767 Read-only 72
118 kWh Meter 0.0 - 999.9 Read-only 72
120 Today’s Date MM/dd/YY Read-only 73
121 Today’s Time hh:mm Read-only 73
150
Show Clock Parameters
(Parameters 151-179)
text string 0 (No) 73
151 Tiime Zone Setup text string 12 (-5 East. US) 73
152 TOD Run Enable 0-23 hours, 0-59 min 12:00 73
154 TOD Run Disable 0-23 hours, 0-59 min 12:00 73
156 TOD Run En 2 0-23 hours, 0-59 min 12:00 73
158 TOD Run Dis 2 0-23 hours, 0-59 min 12:00 74
160 Weekend TOD En 0-23 hours, 0-59 min 12:00 74
162 Weekend TOD Dis 0-23 hours, 0-59 min 12:00 74
171 Reminder 1 Conf. text string 0 (disabled) 74
172 Reminder 1 Time 1-32000 hours 1 74
173 Reminder 1 ETA +/- 32000 hours Read-only 74
174 Reminder 2 Conf. text string 0 (disabled) 74
175 Reminder 2 Time 1-32000 hours 1 74
176 Reminder 2 ETA +/- 32000 hours Read-only 74
177 Reminder 3 Conf. text string 0 (disabled) 75
178 Reminder 3 Time 1-32000 hours 1 75
179 Reminder 3 ETA +/- 32000 hours Read-only 75
201 Input Mode text string Local Only 75
202 Rev Enable text string Forward 75
203 Stop Key Remote text string Coast 76
204 Ref Select text string Vin1 76
205 Vin1 Config text string 0-10V 77
206 Vin1 Offset 0.0% to 100.0% 0.00% 77
= cannot change in Run
Bold type = Level 1 parameter
Note that all parameters can be addressed by adding 40000 to the parameter number. For example, parameter 201 (Input Mode) can be
addressed by Modbus address 40201.
