X5 AC Drive User’s Manual Chapter 7: X5 Parameters
DPD00089A - 75 - © 2009 Vacon Incorporated All Rights Reserved
This parameter displays the length of time until reminder #2 is set. (See “Reminders” on page 58 for more information
on using these parameters.)
177 Reminder 3 Conf.
Default = Disabled
Range: n/a
Level: 2
This parameter configures the reminder to measure the run time or total time before activating the reminder.
The following data values may be assigned to this parameter:
Parameter Value
Description
0 Disabled
1Hour
2 Run Hour
3 Gated Hour
(See “Reminders” on page 58 for more information on using these parameters.)
178 Reminder 3 Time
1
Range: 1 - 32000 hours
Level: 2
Based on parameter 162 (Weekend TOD Dis), this parameter sets the duration of time in hours until reminder #3 is set.
(See “Reminders” on page 58 for more information on using these parameters.)
179 Reminder 3 ETA
Read-only
Range: +/- 32000 hours
Level: 2
This parameter displays the length of time until reminder #3 is set. (See “Reminders” on page 58 for more information
on using these parameters.)
201 Input Mode
Default = Local only
Range: n/a
Levels 1,2
Parameter 201, the Input Mode parameter, configures local and remote control of the Start/Stop source and the
reference source. Refer to “Appendix A: Parameter 201 Options” on page 132, for more information.
The following data values may be assigned to this parameter:
Parameter Value
Run/Stop Control
Local only Local keypad operation only
Remote only Terminal strip operation only
L/R Rem Ref LOCal Keypad Start/Stop and Speed
REMote Keypad Start/Stop, Terminal Strip Speed Reference
L/R Rem Ctl LOCal Keypad Start/Stop and Speed
REMote Keypad Speed Reference, Terminal Strip Start/Stop
L/R Rem Bth LOCal Keypad Start/Stop and Speed
REMote Terminal Strip Start/Stop and Speed Reference
EMOP
{1} {2} {4}
Terminal strip operation using Increase/Decrease buttons
EMOP2
{1} {3} {4}
Terminal strip operation using Increase/Decrease buttons
LOC/EMOP
{1} {2} {4}
LOCal Keypad Start/Stop and Speed
REMote Terminal strip operation using Increase/Decrease
LOC/EMOP2
{1} {3} {4}
LOCal Keypad Start/Stop and Speed
REMote Terminal strip operation using Increase/Decrease
Notes:
1. Electronic Motor Operated Potentiometer (EMOP): simulates the INC/DEC (up/down arrow) keys on a keypad that uses external remote
N/O pushbuttons
2. Commanded output frequency returns to the value of parameter 301 (Min Frequency) when the drive is stopped.
3. Commanded output frequency remains at the previous setpoint when the drive is stopped.
4. The parameters that set the functions of the designated digital inputs for EMOP must be configured as “EMOP+” and “EMOP–” to
complete the implementation.
202 Rev Enable
Default = Forward
Range: n/a
Levels 1,2
Table 7-2: Description of X5 Parameters (Page 5 of 40)
