X5 AC Drive User’s Manual Chapter 3: Receiving and Installation
DPD00089A - 25 - © 2009 Vacon Incorporated All Rights Reserved
3.3 Dissipation Requirements
Table 3-1: Dissipation Requirements for X5 Models in Enclosures (Page 1 of 2)
Model
Required Dissipation for Models Entirely Inside an Enclosure at
Rated Current, 3KHz Carrier Frequency (Watts)
X5C1S010C 47
X5C20010C 48
X5C20020C 71
X5C20030C 92
X5C20050C 132
X5C20075C 177
X5C20100C 263
X5C20150C 362
X5C20200C 550
X5C20250C 653
X5C20300C 779
X5C40010C 34
X5C40020C 48
X5C40030C 71
X5C40050C 91
X5C40075C 114
X5C40100C 155
X5C40150C 304
X5C40200C 393
X5C40250C 459
X5C40300C 458
X5C40400C 695
X5C40500C 834
X5C40600C 776
X5C40750C 988
X5C41000C 1638
X5C41250D 1656
X5C41500D 1891
(continued on next page)
