Vacon X5 User Manual

X5 AC Drive User’s Manual X5 Parameter Summary Table
DPD00089A - v - © 2009 Vacon Incorporated All Rights Reserved
415 Accel Time 3 0.1-3200.0 sec 10.0 sec 83
416 Decel Time 3 0.1-3200.0 sec 10.0 sec 83
417 Accel Time 4 0.1-3200.0 sec 15.0 sec 84
418 Decel Time 4 0.1-3200.0 sec 15.0 sec 84
490 App Macro text string Factory 84
491 Seq Appl text string Disabled 84
492 SIO Visible text string No 84
501 V/Hz Select text string Linear Fixed 85
502 Voltage Boost 0.0-50% 1.0% 85
503 V/Hz Knee Freq 25.0-400.0 Hz 60.0 Hz 85
504 Skip Freq Band 0.2-20.0 Hz 0.2 Hz 86
505 Skip Freq 1 Min Freq-Max Freq 0.0 Hz 86
506 Skip Freq 2 Min Freq-Max Freq 0.0 Hz 86
507 Skip Freq 3 Min Freq-Max Freq 0.0 Hz 86
508 Skip Freq 4 Min Freq-Max Freq 0.0 Hz 86
509 Rated Mtr Volt 100V-690V Model dependent 86
510 Rated Mtr FLA 50% - 200% of ND Rating ND Rating 86
511 Rated Mtr RPM 0-24000 rpm 1750 rpm 86
512 Midpoint Freq 0.0 Hz-V/Hz Knee Freq 60.0 Hz 86
513 Midpoint Volt 0.0-100.0% 100.0% 86
514 Motor RS 0.0-655.35 Ohms Model dependent 86
515 Power Factor 0.50-1.00 0.80 86
516 Slip Comp Enable text string No 87
517 Single Phase text string No 87
519 Find Mtr Data Not active / Motor RS Not active 87
520 Filter FStator 1 - 100 ms 8 ms 87
521 Start Field En text string No 87
522 Filter Time Slip 10 - 1000 ms 100 ms 88
523 Id Percent 0 - 200% Read-only 88
524 Iq Percent 0 - 200% Read-only 88
525 Power Fail Config text string CTS No Msg 88
526 UV Ride-Thru En text string w/ LVT 88
600 Current Lim Sel text string 0 89
601 Cur Lim Mtr Fwd 5%-150% 120% 89
602 Cur Lim Mtr Rev 5%-150% 120% 89
603 Cur Lim Reg Fwd 5%-150% 80% 89
604 Cur Lim Reg Rev 5%-150% 80% 89
605 Cur Lim Freq 0.0 - 400.0 Hz 3.0 Hz 89
606 Ramp Time CL 0.1-3200.0 sec 1.0 sec 89
607 Cur Limit Minimum 0 - 50% 10% 89
608 Restart Number text string 0 90
609 Restart Delay 0-60 sec 60 sec 90
610 Timed OL Select text string 0 (Std Ind 60s) 90
613 Max Regen Ramp 100 - 1000% 300% 91
614 Stability Gain 0 - 10 Model Dependent 91
615 Stability Rate 0 - 1000 Model Dependent 91
700 Vmet Config text string Freq Out 91
701 Vmet Span 0.0-200.0% 100.0% 91
702 Imet Config text string Drive Load 92
703 Imet Span 0.0-200.0% 100.0% 92
704 Imet Offset 0.0-90.0-% 0.0% 92
No. Parameter Name Options Default User Setting See Page
= cannot change in Run
Bold type =Level 1 parameter
Note that all parameters can be addressed by adding 40000 to the parameter number. For example, parameter 201 (Input Mode) can be
addressed by Modbus address 40201.
