613 Max Regen Ramp
Default: 300%
Range: 100 - 1001%
Level 2
This parameter operates as a percentage of the longest ramp time. This time then defines the amount of time a
deceleration to stop can take without causing a “Regen Timeout” fault. For example, if “Decel Time 1” is 5.0 seconds,
“Decel Time 2” is 10.0 seconds, and “Max Regen Ramp” is 300%, a deceleration to stop that takes more than 30
seconds will cause a “Regen Timeout” fault in the drive.
614 Stability Gain
615 Stability Rate
Default: Model dependent
Range: 0-10
Range: 0-1000
Level 2
Both of these parameters can be used to resolve stability problems if they occur. Use Parameter 615 if the load has
significant inertia with respect to the motor itself.
700 Vmet Config
Default: Freq Out
Range: n/a
Levels 1,2
This parameter configures the analog signal that will be applied to the Vmet output pin.
The following data values may be assigned to this parameter:
Para. Value
Description Range Limit
Freq Out Output frequency of the drive Parameter max freq.
Voltage Out Voltage being supplied to the motor Rated motor voltage
Current Out Current being supplied to the motor 200% of drive rating
Drive Load Calculated percentage of drive rating 200% of drive rating
Drive Temp Calculation of total drive temp rating 100% of unit temp rating
Stator Freq Commanded frequency 100% of input config
Power Out Calculated power output of drive 250% of drive rating
+/- Load Percentage torque of drive -200 to +200% of drive rating
(see parameter 105)
PID Fback Allows the analog output to produce
a signal in proportion to the PID
feedback received.
Vin 1 Mirrors the status of the Vin1 input
(see parameter 910) 0-100%
Cin Mirrors the status of the Cin input
(see parameter 911) 0-100%
Vin 2 Mirrors the status of the Vin2 input
(see parameter 912) 0-100%
SIO Config Allows the serial port to set the Vmet
analog output through parameter 920
(SIO Vmet Level) along with parameter
907 (Control Word 2)
Encoder Monitors the status of an encoder
connected to the drive through an option
board.
701 Vmet Span
Default: 100%
Range: 0.0%-200.0%
Level 2
This parameter sets the span of the Vmet analog output.
Table 7-2: Description of X5 Parameters (Page 21 of 40)
