X5 AC Drive User’s Manual Chapter 7: X5 Parameters
DPD00089A - 92 - © 2009 Vacon Incorporated All Rights Reserved
702 Imet Config
Default: Drive Load
Range: n/a
Level 2
This parameter configures the analog signal that will be applied to the Imet output pin. The following data values may
be assigned to this parameter:
Para. Value
Description Range Limit
Freq Out Output frequency of the drive Parameter max freq.
Voltage Out Voltage being supplied to the motor Rated motor voltage
Current Out Current being supplied to the motor 200% of drive rating
Drive Load Calculated percentage of drive rating 200% of drive rating
Drive Temp Calculation of total drive temp rating 100% of unit temp rating
Stator Freq Commanded frequency 100% of input config
Power Out Calculated power output of drive 250% of drive rating
+/- Load Percentage torque of drive -200 to +200% of drive rating
(see parameter 105)
PID Fback Allows the analog output to produce
a signal in proportion to the PID
feedback received.
Vin 1 Mirrors the status of the Vin1 input
(see parameter 910) 0-100%
Cin Mirrors the status of the Cin input
(see parameter 911) 0-100%
Vin 2 Mirrors the status of the Vin2 input
(see parameter 912) 0-100%
SIO Config Allows the serial port to set the Imet
analog output through parameter 921
(SIO Imet Lvl) along with parameter 907
(Control Word 2)
Encoder Monitors the status of an encoder
connected to the drive through an option
board.
703 Imet Span
Default: 100%
Range: 0.0%-200.0%
Level 2
This parameter sets the span of the Imet analog output.
704 Imet Offset
Default: 0.0%
Range: 0.0%-90.0%
Level 2
This parameter sets the offset of the Imet analog output.
Table 7-2: Description of X5 Parameters (Page 22 of 40)
