X5 AC Drive User’s Manual Chapter 2: Technical Characteristics
DPD00089A - 16 - © 2009 Vacon Incorporated All Rights Reserved
2.2 Power and Current Ratings
115 Vac Ratings
Model
number
Normal Duty Input current (A) Output current (A) Heavy Duty Input current (A) Output current (A)
HP kW -- 115 Vac -- 230 Vac HP kW -- 230 Vac -- 230 Vac
X5C1S010C 1 0.75 -- 15 -- 4.2 0.5 0.37 -- 11 -- 2.2
230 Vac Ratings
Model
number
Normal Duty Input current (A) Output current (A) Heavy Duty Input current (A) Output current (A)
HP kW 200 Vac 230 Vac 200 Vac 230 Vac HP kW 200 Vac 230 Vac 200 Vac 230 Vac
X5C20010C 1 0.75 5.6 4.8 4.8 4.2 0.5 0.37 2.9 2.5 2.5 2.2
X5C20020C 2 1.5 9 7.8 7.8 6.8 1 0.75 5.6 4.8 4.8 4.2
X5C20030C 3 2.2 12.7 11 11 9.6 2 1.5 9 7.8 7.8 6.8
X5C20050C 5 4 20.2 17.5 17.5 15.2 3 2.2 12.7 11 11 9.6
X5C20075C 7.5 5.5 29.2 25.3 25.3 22 5 4 20.2 17.5 17.5 15.2
X5C20100C 10 7.5 37.2 32.2 37.2 28 7.5 5.5 29.2 25.3 25.3 22
X5C20150C 15 11 52.1 46.4 48.3 42 10 7.5 37.2 32.2 37.2 28
X5C20200C 20 15 68.3 57.4 62.1 54 15 11 52.1 46.4 48.3 42
X5C20250C 25 18.5 82.3 73.8 78.2 68 20 15 68.3 57.4 62.1 54
X5C20300C 30 22 96 84 92 80 25 18.5 82.3 73.8 78.2 68
NOTE: All 230 Vac models can be operated at single-phase, with 50% derating
460 Vac Ratings
Model
number
Normal Duty Input current (A) Output current (A) Heavy Duty Input current (A) Output current (A)
HP kW 380 Vac 460 Vac 380 Vac 460 Vac HP kW 380 Vac 460 Vac 380 Vac 460 Vac
X5C40010C 1 0.75 3.0 2.4 2.4 2.1 0.5 0.37 1.6 1.3 1.3 1.1
X5C40020C 2 1.5 5.2 3.9 3.8 3.4 1 0.75 3.0 2.4 2.4 2.1
X5C40030C 3 2.2 7.2 5.6 5.1 4.8 2 1.5 5.2 3.9 3.8 3.4
X5C40050C 5 412 8.88.97.63 2.2 7.2 5.6 5.1 4.8
X5C40075C 7.5 5.5 15 12.8 12 11 5 412 8.8 8.9 7.6
X5C40100C 10 7.5 19.7 16.3 15.6 14 7.5 5.5 15 12.8 12 11
X5C40150C 15 11 30.9 25.8 23 21 10 7.5 19.7 16.3 15.6 14
X5C40200C 20 15 40 33.3 31 27 15 11 30.9 25.8 23 21
X5C40250C 25 18 46.3 40 37 34 20 15 40 33.3 31 27
X5C40300C 30 22 57.5 47.8 43 40 25 18 46.3 40 37 34
X5C40400C 40 30 73.2 62.4 61 52 30 22 57.5 47.8 43 40
X5C40500C 50 37 82 78 71 65 40 30 73.2 62.4 61 52
X5C40600C 60 45 94 80 86 77 50 37 82 78 71 65
X5C40750C 75 55 114 99 105 96 60 45 94 80 86 77
X5C41000C 100 75 149 129 140 124 75 55 114 99 105 96
X5C41250D 125 90 168 156 168 156 100 75 140 124 140 124
X5C41500D 150 110 205 180 205 180 125 90 168 156 168 156
X5C42000D 200 132 240 240 240 240 150 110 205 180 205 180
