X5 AC Drive User’s Manual Chapter 4: Connections
DPD00089A - 35 - © 2009 Vacon Incorporated All Rights Reserved
X5C40010C — — — 6 6 —
X5C40020C — — — 10 6 —
X5C40030C — — — 10 10 —
X5C40050C — — — 15 15 —
X5C40075C — — — 20 20 —
X5C40100C — — — 25 20 —
X5C40150C — — — 40 35 —
X5C40200C — — — 50 40 —
X5C40250C — — — 60 50 —
X5C40300C — — — 80 60 —
X5C40400C — — — 100 80 —
X5C40500C — — — 110 100 —
X5C40600C — — — 125 100 —
X5C40750C — — — 150 125 —
X5C41000C — — — 200 175 —
X5C41250D — — — 225 200 —
X5C41500D — — — 250 225 —
X5C42000D — — — 300 300 —
X5C50010C — — — — — 6
X5C50020C — — — — — 6
X5C50030C — — — — — 10
X5C50050C — — — — — 10
X5C50075C — — — — — 15
X5C50100C — — — — — 20
X5C50150C — — — — — 30
X5C50200C — — — — — 40
X5C50250C — — — — — 50
X5C50300C — — — — — 50
X5C50400C — — — — — 70
X5C50500C — — — — — 80
X5C50600C — — — — — 90
X5C50750C — — — — — 110
X5C51000C — — — — — 150
X5C51250D — — — — — 175
X5C51500D — — — — — 200
X5C52000D — — — — — 250
Table 4-6: Fuse Ratings (Page 2 of 2)
Model Number
Fuse Size
115 Vac
JJS/JJN
Fuse Size
208 Vac
JJS/JJN
Fuse Size
230 Vac
JJS/JJN
Fuse Size
380 Vac
JJS
Fuse Size
460 Vac
JJS
Fuse Size
575 Vac
JJS
