Vacon X5 User Manual

X5 AC Drive User’s Manual Chapter 4: Connections
DPD00089A - 37 - © 2009 Vacon Incorporated All Rights Reserved
40100 7.5 120 68% 75 8,112 109%
40150 11 120 45% 47 12,944 116%
40200 15 120 34% 47 12,944 87%
40250 18 120 27% 47 12,944 69%
40300 22 120 23% 39 15,600 70%
40400 29.8 60 34% 20 30,420 102%
40500 37.3 60 27% 20 30,420 82%
40600 45 60 23% 15 40,560 91%
40750 55 60 18% 10 60,840 109%
41000 75 60 14% 10 60,840 82%
41250 90 60 11% 10 60,840 65%
41500 110 60 9% 10 60,840 54%
42000 132 60 7% 10 60,840 41%
50010 .75 120 1058% 110 8,607 1154%
50020 1.5 120 529% 110 8,607 577%
50030 2.2 120 353% 110 8,607 385%
50050 3.7 120 212% 110 8,607 231%
50075 5.5 120 141% 91 10,404 186%
50100 7.5 120 106% 91 10,404 139%
50150 11 120 71% 62 15,269 136%
50200 15 120 53% 62 15,269 102%
50250 18 120 42% 62 15,269 82%
50300 22 120 35% 62 15,269 68%
50400 29.8 60 53% 24 39,447 132%
50500 37.3 60 42% 24 39,447 106%
50600 45 60 35% 15 63,115 141%
50750 55 60 28% 15 63,115 113%
51000 75 60 21% 20 63,115 85%
51250 90 60 17% 10 94,672 102%
51500 110 60 14% 10 94,672 85%
52000 132 60 11% 10 94,672 63%
Table 4-7: X5 Dynamic Braking Capacity (Page 2 of 2) (* Note that the asterisked X5 model numbers cannot
have external braking added)
Model KW
Standard
Resistance
(ohms)
Standard DB
(% of Drive
Power)
Min. Allowed
Res. (ohms)
Max. Peak
Watts
Max. Ext. DB
(% of Drive
Power)
