Map of Major Components
Replacement Procedures
LigaSure Vessel Sealing Generator Service Manual 8-3
Map of Major Components
Figure 8-1 identifies the major components in the generator. The map does not
show the control board, which resides on the inside of the right wall of the
generator.
Figur e 8 - 1 .
The location of major components
in the generator
Control Board (resides on the inside of this wall)
Footswitch
Board
RF Board
Low Voltage (LV)
Power Supply Board
High Voltage (HV)
Power Supply Board
Front Panel
