Performance Characteristics
4-4 LigaSure Vessel Sealing Generator Service Manual
Activation Tone
Seal Complete Tone
Regrasp Tone
Alarm Tone
Serial Port
RS-232 compatible; 9600 baud, 8 data bits, 1 stop bit, no parity
A 9-pin connector supporting the following signals:
• pin 2 – isolated transmit (serial data output transmit line)
• pin 3 – isolated receive (serial data input receive line)
• pin 5 – isolated ground (reference for transmit and receive)
Volume (adjustable) 45 dBA minimum
Frequency (nominal) Seal Mode - 440 Hz
Macrobipolar Mode - 520 Hz
Bipolar Mode - 660 Hz
Duration Continuous while the generator is activated.
Volume (not
adjustable)
65 dBA minimum
Frequency 440 Hz
Duration Two short beeps when vessel sealing cycle is
complete
Volume (not
adjustable)
65 dBA minimum
Frequency 780 Hz
Duration Four pulsed tones
Volume (not
adjustable)
65 dBA minimum
Frequency 985 Hz - 780 Hz; 985 Hz nominal
