Power Entry Module
8-30 LigaSure Vessel Sealing Generator Service Manual
5. Install the front panel. For further information, refer to Front Panel and
Display Board in this chapter.
6. Position the RF heat sink bracket on the heat sink and the chassis. Replace the
two screws (M4 x .7 x 8) that secure the RF heat sink bracket to the heat sink
and the chassis.
7. Install the cover. For further information, refer to Cover in this chapter.
8. Connect the power cord to the wall receptacle.
Power Entry Module
Replacing the power entry module requires removing the cover, disconnecting
cables, removing screws, and lifting the module out of the chassis. Installing a
new power entry module reverses the process.
Tools Needed
• Phillips head screwdriver
Remove the Power Entry Module
1. Turn off the generator. Disconnect the power cord from the wall receptacle.
2. Disconnect the power cord from the power entry module.
3. Remove the cover.
4. Disconnect three wires:
5. Remove two screws (M3 x .5 x 8) that secure the power entry module to the
rear panel.
6. Slide the module out the rear panel.
Name Location Wires Colors
AC switch 2 Pin P, top of rear of module 1 brown
AC switch 2 Pin N, top of rear of module 1 blue
Chassis ground Center bottom of rear of
module
2 green/yellow
