Power Switch
8-22 LigaSure Vessel Sealing Generator Service Manual
Power Switch
Replacing the power switch requires removing the cover and the front panel,
disconnecting the wires from the back of the power switch, then disconnecting the
power switch and taking it out of the front panel. Installing the power switch
reverses the process.
Tools Needed
• Phillips head screwdriver
Remove the Power Switch
1. Turn off the generator. Disconnect the power cord from the wall receptacle.
Disconnect any footswitches or handsets currently connected to the generator.
2. Remove the cover.
3. Remove the front panel:
a. Disconnect three cables:
b. Remove four screws (M4 x .7 x 8):
c. Two screws, with washers – one each on the left and right upper corners
formed at the front and sides of the unit.
d. Two screws on the underside of the front panel, one under each handset
receptacle.
Name Ref Location Wires Colors
Control board
ribbon cable
Control board
RF out cables
(2)
J10 &
J11 on
RF
board
Near front edge of
RF board
4 (per
cable)
brown, blue,
yellow, and white
