Performance Characteristics
4-2 LigaSure Vessel Sealing Generator Service Manual
Performance Characteristics
General
Dimensions and Weight
Operating Parameters
Output configuration Isolated output
Cooling Natural convection
Display Two (2) digital seven-segment displays: 1.9 cm
(0.75 in.) each
Six (6) bar graph displays: 1.0 cm (0.4 in.) each
Mounting A Valleylab cart (UC8009) or a stable flat surface
Width 38.6 cm (15.2 in.)
Depth 40.6 cm (16.0 in.)
Height 12.7 cm (5.0 in.) not including feet
Weight 5.9 kg (13 lbs)
Ambient temperature
range
10° to 40° C (50° to 104° F)
Relative humidity 15% to 90%, noncondensing
Atmospheric pressure 700 to 1060 millibars
Warm-up time If transported or stored at temperatures outside the
operating temperature range, allow one hour for the
generator to reach room temperature before using.
