CHAPTER
5
LigaSure Vessel Sealing Generator Service Manual 5-1
5Principles of Operation
This chapter provides detailed information about how the LigaSure
vessel sealing generator functions and how the internal
components interact.
The circuitry resides on eight printed circuit boards: the control
board, the display board, the footswitch board, the low voltage
power supply board, the high voltage power supply board, the
Radio Frequency (RF) board, and two smart connector boards.
This chapter includes the following information:
• A block diagram that illustrates how the generator components
interconnect
• A general description of how the generator works
• A detailed description of the circuitry for each printed circuit board
