Fuses
8-34 LigaSure Vessel Sealing Generator Service Manual
F ig u re 8- 1 9.
The fuse on the HV power supply
board
5.
Replace the blown fuse with a new fuse:
2 A, 250 V, 5 x 20 mm, fast acting
6. Install the HV power supply board. For more information, refer to High
Voltage (HV) Power Supply Board in this chapter.
7. Install the cover. For further information, refer to Cover in this chapter.
8. Connect the power cord to the power entry module and to the wall receptacle.
Fuse
