FITTING INSTRUCTION
99
OIL FLOW CONTROL VALVE
1
26.10.1992
29.04.1993 6000---8400 (4)
Oil f l o w control valve 32530310.
--- Depending on the tractor serial number, it must be
observed modifications on the valve bracket and
onthepumpsideendplate.
--- ORDER NUMBER:
mounting kit 32530310
(incl. valve and mounting parts)
Fixing screws:
32691400 4pcs (2 valves)............ .....
32607400 4pcs (3 valves)............ .....
32691500 4pcs (4 valves)............ .....
Extra parts needed up to ser no ---> 657670 :
Pump side end plate 32556410 1... .
Plug GR0286 3................. ..
O --- r i n g KH4081 3............... ..
Hose 32691700 1................. .
Nut (M10) JB1110 1............ ...
WORKING INSTRUCTION:
--- Remove the RH side rear wheel. Remove the
access hole cover on the RH side rear mudguard.
--- Remove the valve block studs and the end plates.
Disconnect the pressure hose from the pump side
end. Unscrew the intermediate plate bolts and
remove the intermediate plate.
--- Detach th e angle union (GS 9449) and the upper
plug (GR 0286) and change over their places.
--- Drill a ø12 hole mm through the lever console
according to the figure. Drill or cut a hole ø 4 mm
through the lever rubber bellows (estimate the
place of the hole).
--- Assemble the valve block and the oil flow control
valve using new studs. Fit the pressure pipes. Fit
the valve block attaching screws (HA 8340 2 st)
according to the figure. Fit the control rod of the
oil flow control valve.
Fit the other detached parts.
EXTRA WORK NEEDED UP TO SERIAL NUMBER
--- > 657670:
--- Fit new plugs onto the new pump side end plate
and the angle union and the pressure control
valve. Fit the pressure pipe and hose.
--- Make from steel sheet a plate (see picture) and
weld it onto the valve block bracket. Drill a M10
hole according to the measurements in the pic-
ture. Do correction painting.
