Model Code Page
33. Agroline ---instrument
2. Calibrating Agroline for different tyres
Thecalibrationoftheinstrumentmustbedoneifanewinstru-
ment or the rear tyre sizes have been changed.
With the help
of the calibration the Agroline---instrument can show the cor-
rect driving speed and driving distance.
Do not pause more than 10 seconds during calibration, be-
cause the display will be switched into the normal mode.
--- switch on current. Choose the driving distance in the upper
row by pressing the right edge of the switch (30).
--- press the right edge of the switch (30) for about 3sec. until
the display is switched into the setting mode (minutes start to
flas).
--- p r e s s t h e s w i t c h ( 30) right edge quickly, at which time m
starts to flash in the display.
--- select the correct code value in the display by pressing the
switch (30) left edge. When the left edge is kept down,
numbers are changed cont inually.
--- when the code is correct, the display is switched to the nor-
mal mode after 10 seconds. or by pressing the right edge of
the switch (30) for over 3seconds.
--- if a correct code value you passed, scan forwards up to
code 400, after which the code starts from 100.
Note! The code number could be between 100---400.By
pressing switch (30) the code value is changed from a
smaller value to a greater one. The code numbers with vari-
ous tyres are shown in the table below (same as for Agro-
d a t a --- i n s t r u m e n t ) .
Note! If tractor tyres cannot be found in the table below , the
code number can be calculate as follows:
Example:
--- A g r o l i n e --- i n s t r u m e n t p r e s e n t c o d e n u m b e r i s 170.
--- Trac t or max. driving speed is 40 km/h.
Agroline ---instrument shows max. driving speed of 39 km/h
when driving the tractor.
ThecodevalueX=174 can be calculated as follows:
Code numbers with different tyre sizes and transmission types (Mezzo ja Mega):
6200---6400 6800 ---8550 6200---6400 6800---8550
Rear wheel
40 km/h 40 km/h
50 km/h
traffic model
Ta k a p y ö r ä
40 km/h 40 km/h
50 km/h
traffic model
13.6---38 216 216 197 480/80R42 181 181 166
13.6R38 215 215 197 520/70R34 203 203 186
14.9R38 209 209 191 520/70R38 193 193 177
16.9---34 214 214 196 520/70R38 191 191 174
16.9R34 212 212 194 520/85R38 181 181 166
16.9R38 201 201 184 520/85R42 169 169 155
18.4---34 207 207 190 540/65R38 200 200 183
18.4---38 195 195 178 580/70R38 182 182 167
18.4R38 195 195 178 600/65R34 203 203 186
20.8R38 183 183 167 600/65R38 193 193 177
20.8R42 173 173 159 600/65R38 192 192 176
230/95R48 200 200 183 620/75R30 199 199 182
270/95R48 194 194 178 650/65R38 184 184 168
340/85R38 215 215 197 650/65R42 175 175 160
420/85R38 199 199 182 650/75R38 173 173 159
460/85R38 190 190 174 680/75R32 183 183 168
480/70R38 198 198 181
X=
170 x 40
39
=
174
