32. Electro---hydraulic power lift
15. 4. 1995
6000--8400 320 3B
1. 1. 1994
Wiring diagram 662343---F17106
Note! On 6000---8400 models the diff. lock is disengaged
when the lift/lower switch is turned to the transport position,
see Autocontrol II under code 311. In addition, the lift/lower
switch has a middle position which stops the movement of
thelowerlinks.Seealsopictureonpage310/6A.
Note! With effect from serial number 668103 (AC 2.1), the
power lift has a forced ---lowering switch S11E.
S y m --- Code
bol Component no
A1E Autocontrol electronic unit 84
A2E Autocontrol, switch panel 87
A3E Compensator 82
B1E Position sensor 81
B2E Draft sensor, right 81
B3E Draft sensor, left 81
E1E Illumination, switch panel 87
E2E Illumination, position control knob 89
R1E Potentiometer, position control 87
S1E Push button, mudguard, lifting, right 84
S2E Push button, mudguard, lowering, right 84
S3E Push button, mudguard, lifting, left 83
S4E Push button, mudguard, lowering, left 83
S5E Push button, cabin, lifting 85
S6E Push button, cabin, lowering 85
S7E Switch, lowering speed 87
S8E Switch, transport height 87
S9E Switch, mixing/sensitivity 87
S10E Rocker switch, lift/lower 88
S11E Rocker switch, forced lowering 88
X2E Connector, 9 pins, supply, push buttons
Y1E Solenoid valve, lowering 81
Y2E Solenoid valve, lifting 81
Wire colours
Ru = brown
Pu = red
Ke = yellow
Si = blue
Mu = black
Vi = green
Va = white
Li = lilac
