35. Autocontrol IV
15. 4. 1995
6600E
8100E-- 8750E
350 13
1. 1. 1995
Sym-- Cod-
bol Component no
S18 Engine temperature sender unit (stop) 16
(S19) Air cond. compressor press. switch 54
S20 Brake light contact, left 65
S23 Switch, Delta Power Shift, selector 102
(S23) Extra sw., Delta Power Shift, selector 102
S24 Switch, Delta Power Shift release 100
(S26) Switch, rear fog light 35
(S27) Switch, back buzzer
S28 Switch, PTO 540 66
S29 Switch, PTO 1000/ 540E 66
(S31) Switch, floor fan 57
(S32) Switch, rear window washer and wiper 48
(S33) Change over sw., head lights up 23
(S34) Switch, water pump 97
(S35) Rear steering prevention 94
S36 Switch, Control stop 4
(S37) Switch, Agrodata---unit 94
(S38) Switch, Front PTO
S42 Door switch, right, cab light 46
S43 Door switch, left, cab light 46
V 1...4 Diodes (Y1, Y2, Y3, Y4, Y6)
V 3 Diod, Control stop
X 1 Connector, 9---pole, distribution box
X 2 Connector, 9---pole, distribution box
X 3 Connector, 9---pole, distribution box
X 4 Connector, 9---pole, distribution box
X 5 Connector, 9---pole, distribution box
X 6 Connector, 9---pole, distribution box
X 7 Connector, 9---pole, distribution box
(X8) Conn.,2---pole,powersocket 92
X 9 Connector, 9---pole, combination control
X10 Connector, 9---pole, combination control
X11 Connector, 9---pole, upwards
X12 Connector,9---pole,rearwards,right
X13 Connector, 9---pole, solenoid valves.
X14 Connector,9---pole,rearwards,left
(X15) Connector, 3---pole, air cond., diodes
(X16) Connector, 3---pole, cigarette lighter,
current socket
X17 Trailer socket, 7---pole 32
(X18) Connector, 2---pole, rear window washer
X19 Connector, 24---pole, front wall
X20 Connector, 9---pole, front direction
indicator
(X22) Connector, 2 pole, rot. roof light
X23 Connector, 3---pole,Delta Power Shift,
extra switches
X24 Connector, 9 pole, upwards
(X25) Connector,9pole,Agrodata---instr.
X26 Connector, 26 pole, instr. left, white.
X27 Connector, 26 pole, instr. right, blue
( X 2 9 ) C o n n e c t o r, 2 --- p o l e , s t o p --- a l a r m
X 3 1 S o c k e t , 2 --- p o l e , P T O --- e m e r g . st o p 6 8
X32 Connector,1pole,electricstop
(X33) Connector, 3---pole,fog light, rear
(X34) Connector,9---pole,Agrodatasensor
(X35) Connector, 9---pole, ETB supply
(X49) Connector,2---pole,seat
Y 1 Solenoid valve, diff. lock 63
Y 2 Solenoid valve PTO 68
Y 3 Solenoid valve 4WD 66
Y 4 Solenoid valve, Delta Power Shift 100
(Y 5) Solenoid valve compressor (air.cond.) 54
Y 6 Solenoid valve, Delta Power Shift 102
(Y7) Solenoid valve, rear steering prevention 94
Y8 Solenoid, engine stop 4
(Y9) Solenoid, front PTO
GR1 Earth lead, rear lights, solenoids
GR2 Earth lead, roof
GR4 Earth lead, autocontrol
GR5 Earth lead, cable harness, instr. panel
GR7 Earth lead, battery
GR8 Earth lead, headlights
GR9 Earth lead, cabin
GR10 Earth lead, electrical stop
AUTOCONTROL POWER LIFT:
A1E Autocontrol 84
A2E Autocontrol, switch panel 87
S y m --- C o d -
bol Component no
A3E Compensator 82
B1E Position sensor 81
B2E Draft sensor, R.H 81
B3E Draft sensor, L.H 81
E1E Lighting, switch panel 87
E2E Lighting, position potentiometer 88
R1E Potentiometer, pos .control 87
S1E Switch, rear operation, r.h., lifting 84
S2E Switch, rear operation, r.h., lowering 84
S3E Switch, rear operation, l.h., lifting 83
S4E Switch, rear drive, l.h., lowering 83
S5E Switch, inside, lifting 85
S6E Switch, inside, lowering 85
S7E Switch, lowering speed 87
S8E Switch, top limit 87
S9E Switch, sensitivity /mixing 87
S10E Switch, lifting /lowering 88
S11E Switch, forced lowering 86
X2E Connector housing, 9 pole.,
EH--- supply, rear push buttons
Y1E Solenoid valve, lowering 81
Y2E Solenoid valve, lifting 81
AC IV UNIT:
A1C ACIV--- control unit (red connector) 61,66
A2C ACIV--- control unit 61,66
B1C Speed sensor, rear wheel 61
B2C Speed sensor, gearbox 61
B3C Speed sensor, PTO 61
B4C Speed sensor, engine 61
B5C Velocity sensor, front axle 68
B7C Radar 65
B8C Potentiometer, accelerator 63
B9C Temperature sensor, thermostart 19
B10C Outside temperature sensor 18
H1C Buzzer, slip 89
H2C Led, slip control
S1C Switch, diff. lock, autom./ manual 68
S2C Switch, Delta Power Shift autom./man. 102
S3C Switch, 4WD, autom./manual 67
S4C Switch, steering angle 69
S5C Switch, slip control
X1C Connector housing, 9--- pole, sources/solenoids
X2C Connector housing, 15---pole, wheel sensors
X3C Connector housing, 9---pole, rear socket
X5C Connector housing, 15---pole, sensors switches
X6C Conn. housing,12---pole,EH---card 87
X7C Connector housing, EH wiring assy
X10C Connector housing, 8--- pole, RS232/RS485 61
X11C Conn. housing, 9---pole, display 61
X12C Rear socket, 13---pole 71
Wire colours
Ru = brown
Pu = red
Ke = yellow
Si = blue
Mu = black
Vi = green
Va = white
Ha = grey
Li = lilac
