39
Model Code Page
21. Engine
1. 6. 1999
6000--8950
210 17
1. 4. 1997
The picture above shows the air intake system of the 8400
tractor. 8400 has a turbocharged, 6---cylinder engine with an
output of 140 hp (103 kW). The turbochargertype isSchwitzer
S2B.
Air filter on later 8200 and 8400. In this filter the filter elements
are a little bigger than on other models. Also a pipe, which
removes impurities with the aid of the suction created by
exhaust gas flow,is standardequipment.Theair intakecover-
ing above the filter has a net, which filters larger impurities.
ThefilterelementsareaccessibleafterremovingtheLHside
engine hood plate. There is a wing nut at the end of the filter
housing.
Note! 6200, 6800, 8000R and 8050---8750 tractors also have
this filter and later all Mezzo/Mega---series tracto rs.
