Valtra 6850 - Page 446

405
Model Code Page
35. Autocontrol IV
15. 5. 1996
6600E-- 8750E
350 21
S y m --- C o d e
bol Component no
AC IV UNIT:
A1C ACIV --- control unit (red connector) 62---71
A2C ACIV --- control unit 62---71
B1C Speed sensor, rear wheel 62
B2C Speed sensor, gearbox 63
B3C Speed sensor, PTO 64
B4C Speed sensor, engine 65
B5C Velocity sensor, front axle 66
B7C Radar 67
B8C Potentiometer, accelerator 65
B9C Temperature sensor, thermostart 63
B10C Outside temperature sensor 66
S1C Switch, diff. lock, autom./ manual 71
S2C Switch, Delta Power Shift autom./man. 102
S3C Switch, 4WD, autom./manual 70
S4C Switch, steering angle 64
X1C Connector housing, 9 ---pole,
sources/solenoids
X2C Connector housing, 15---pole,
wheel sensors
X3C Connector housing, 9---pole, rear
socket 72
X4C Connector, 9---pole, sensors, tractor’s front part
X5C Connector housing, 15---pole,
sensors, switches
X6C Not in use
X7C Connector housing, 3---pole, EH wiring assy
X10C Connector housing, 8 ---pole,
RS232/RS485 68
X11C Conn. housing, 9---pole, display 71
X12C Rear socket, 13---pole 72
Wire colours
Ru = brown
Pu = red
Ke = yellow
Si = blue
Mu = black
Vi = green
Va = white
Ha = grey
Li = lilac
