FITTING INSTRUCTION 08.12.1995 26000---8400 39
IMPLEMENT CONTROL SYSTEM
(5)
28.07.1993
FITTING:
--- Disconnect the battery earth cable. Remove the le-
ver console side panel.
--- Drill holes ø 9 mm (2 pcs) in the RH side side pillar,
see picture. Fasten support 2,housing13 and
control unit 1.
--- H o l d e r 5 is fitted on the driver’s right in the rear wall
of the cavity on the lever console.
Fit the holder into place and mark places for the fi-
xing holes (2 pcs). Drill holes ø 3 mm.
Make a 35 x 35 m hole in the middle of the holes for
lead---in of the wires.
--- Push the wiring loom 11 connector ”X1T” under
the lever console and further through the holder 5
so that the connector is locked in place. Fasten the
holder 5 onto the panel.
Connect the cable from the control unit to the con-
nector.
--- Detach the socket support in the rear of the tractor.
Move the socket to a new support 7 (do not discon-
nect the wires).
--- Pass wires to the implement socket 8 (”X3T”) insi-
de the beam below the rear window. Pass the wires
out of the LH side lead---in hole.
--- Fa s t e n t h e s oc k e t 8 onto the bracket 7 at the LH
side fastening point.
Connect wires to the socket, see picture. Fasten
the bracket into place.
--- Connect the wiring loom 11 connector equipped
with an earth shoe under the earth screw in lever
console bottom (driver’ seat side) (lead---in hole
cover fixing screw).
--- Draw the wiring loom 11 front end together with
other wires along the lever console edge and furt-
her along the cable channel under the floor mat in-
to the steering wheel console.
Fasten the wire with a clip to the main wiring loom.
--- Remove the interval wiper K9 holder fixing screw
and fasten inplace a holder of relay 12 (”K1T”) in
the wiring loom.
Connect the interval wiper holder to the relay 12
holder. Push the relays into the holders.
On the latest models the relay ”K1T” is fastened in
theLHsideloweredgeoftheelectriccentrepro-
tective plastic. There is a fixing screw fitted.
