720
Model Code Page
42. Gearbox
8. 11. 1990
6000--8750 423 16
2470
9. When the bearing preload is correct, lock the adjusting flan-
ges with loc king plates. Tighten the bearing flange screws.
10.Bend and connect the differential lockpipe on the LH side.
Note! TheLHsideadjustingflangecanbeinsuchaposition
that the diff. lock pipe connection is not at the pressure pipe.
Then remove the bearing flange screws and turn the bearing
and adjusting flanges together, until the connection is oppo-
site the pressure pipe and can be connected. Then the bea-
ring preload does not change.
