931
Model Code Page
61. Steering system
1. 1. 1995
6000--8750 610 3
8. 11. 1990
Special tools
1. Equipment for measuring s teering system working pressure (pressure at test point 14,0---15,5 MPa)
Pressure measuring kit 31965000 includes the above shown hose and pressure gauge. These parts can also be ordered sep-
arately.
2. Equipment for measuring shock valve opening pressure (opening pressure 19,0---21,5 MPa).
Note! T---connector GS9276 has thread 3/4---16 for connecting hand pump hose. The pressure measuring kit 31965000 does not
include the hand pump
