2920 Float & Tape Transmitter 5 Display and Configuration Interface

100 Installation and Operations Manual

Calibration

The Calibration menu selection contains shortcuts to RTD, AI, and AO data.

Note After the Calibration menu selection, the menu rolls over to beginning (System

Data) and continues through the menu sequence.

Calibrate Level Shortcut

You can use a shortcut to calibrate the product level for the 2920. This procedure opens the

Cal Level configuration parameter in the Basic Setup menu.

To use the Cal Level shortcut:

1. Press and hold the C button for 4 to 5 seconds.

2. The display opens the Cal Level so you can set it.

Basic Setup menu and Cal Level description can be found in “Basic Setup”.

Note Level can be entered in either decimal format (nnn.nnn) or in Ft-In-16ths format

(nnn-nn-nn.) If the level is entered in decimal format, the 2920 assumes the value is the

same unit as specified in the transmitter setup (Basic Setup > Level Disp Units.)

The level can be entered in Ft-In-16ths format regardless of the level display units. If the

transmitter is set up for level units other than Ft-In 16ths, the level is converted to the

transmitter level display units automatically.

Main Menu

Calibration

System Data

Basic Setup



Calibration

RTDConfig Params
