2920 Float & Tape Transmitter 5 Display and Configuration Interface
62 Installation and Operations Manual
P
System Time
The System Time (or Clock) point is used to set parameters that relate to time (such as time
zone) and timing (such as System Time or ticks). System Time menu presents 4 options:
• Display Only — data display, such as time zone
• Commands — commands that can be executed from the System Time menu
• Config Params — parameters that are used to configure data in System Time data,
such as System Time
• All Params — scrolls through the Display, Commands, and Config parameters in one
menu
Display Only Description
Comm Status Online or offline for active communications.
State Current Communication state, this value is dependent
on the type of communications protocol used by the
port.
Cmd Current communications command which is protocol
dependant.
Status Protocol dependant.
Value Protocol dependant.
Comm Errors Number of communication errors.
Num Trans Number of communication transactions.
Elapse Time of last update.
Pnt Status Byte value indicating status of point. Values are:
0: No error
Pnt Checksum CRC-16 Checksum of point's static configuration
parameters.
Config Params Description
Protocol RTU_Slave
Disabled
Baud Rate Select the baud rate from the list presented.
Comm Params Select from:
8E - 8 bits, even parity
8O - 8 bits, odd parity
8N - 8 bits, no parity
Timeout Reserved for compatibility.
Response Delay The amount of time (if any) a slave protocol will wait to
respond after valid request.
All Params Lists all Display and Config Params in a list.
