Varec 2920 - Status Bit Register Map

MODBUSAppendix A — MODBUS Implementation
Varec, Inc. 167
Status Bit Register Map
8Crit High Level
9 Level Deadband
10 Crit Low Temp
11 Adv Low Temp
12 Adv High Temp
13 Crit High Temp
14 Temp Deadband
15 Min Level
16 Max Level
17 Min Temp
18 Max Temp
19 Reserved
20 Manual Temp
21 Calibration Level
Register Number Description
Register Number Description
0 – 15 AlmStat
16 – 31 Diag Stat
32 – 47 Cmds
48 - 63 Reserved
64 - 79 Reserved
80 - 95 DO Output Control
96 - 111 DO Output Power-up State
112 - 127 DO State
128- 143 DO1 Assign
144 - 159 DO2 Assign
160 - 175 DO3 Assign
176 - 191 DO4 Assign
192 - 207 DO1 Output Duration
