Varec, Inc. 17
Chapter 4
Wiring
This chapter describes how to connect wiring terminations for the 2920 FTT. Wiring should be
done after the unit is mounted as described in "Mounting".
Overview
The wiring of the junction boxes to the 2920 FTT varies based on the order options. The 2920
FTT will be configured with additional junction boxes depending on the ordered options. The
maximum number and arrangement of junction boxes is shown in the following figure.
The following figure shows a typical mounting arrangement with the Varec 2500 gauge.
I.S. HART
Junction Box
Expansion
Junction Box
Junction Box
I.S. HART
Digital Display &
Main Junction Box
Expansion
Junction Box
Digital Display &
Main Junction Box
To Next Page
