2920 Float & Tape Transmitter 13 Specifications
142 Installation and Operations Manual
Switches and Indicators
Fuse
Input/Output Options
Caution! Do not exceed voltages specified above.
Physical
Item Description
Graphical Liquid Crystal Display Four-button capacitive user interface
Reset Switch Sends reset signal to processor
Status Indicators 4 LEDs
Limit Switches 2 or 4 SPDT limit switches (optional):
• 11 amp - 125, 250, 277 VAC
• 4 amp - 125 VAC Tungsten filament Lamp Load
• 1/3 HP - 125 VAC, 250 VDC
• 1/2 amp - 125 VDC, 1/4 amp - 250 VDC
Item Description
F1 Fuse (80 mA, 250 VAC, Slow-blow) Littelfuse 0218.080HXP
Schurter 0034.3106
Item Description
Digital Inputs 3.3 V pull up voltage, (100 ohm maximum for activation)
Item Description
Net Weight 13 lbs (5.9 kg)
Shipping Weight 18 lbs (8.2 kg)
Enclosure Explosion proof die-cast aluminium
Conduit Entries Conduit junction box(s) supplied with 2 x 3/4” NPT for
customer use.
