5 Display and Configuration Interface
Varec, Inc. 67
Tank Data
The Tank data item displays specific parameters and allows configuration of the tank point
functions.
Tank Data menu presents 3 options:
• Display Only — data display, such as level or temperature
• Config Params — parameters that are used to configure data in Tank data, such as
critical low temperature or advise low level
• All Params — scrolls through the Display and Config parameters in one menu
Config Params
Cal. Point #1 These parameters are used to provide additional
calibration to the RTD circuit. This Cal. Point value is 20
ohms. These parameters adjust the interpolation points
used in temperature calculations.
Cal. Point #2 These parameters are used to provide additional
calibration to the RTD circuit. This Cal. Point value is 60
ohms. These parameters adjust the interpolation points
used in temperature calculations.
Cal. Point #3 These parameters are used to provide additional
calibration to the RTD circuit. This Cal. Point value is 100
ohms. These parameters adjust the interpolation points
used in temperature calculations.
Cal. Point #4 These parameters are used to provide additional
calibration to the RTD circuit. This Cal. Point value is 140
ohms. These parameters adjust the interpolation points
used in temperature calculations.
Cal. Point #5 These parameters are used to provide additional
calibration to the RTD circuit. This Cal. Point value is 180
ohms. These parameters adjust the interpolation points
used in temperature calculations.
Avg Filter Value between 1-10 indicating the number of
temperature samples used in temperature filtering. The
default value is 4.
All Params Lists all Display, Commands, and Config Params in a list.
