2920 Float & Tape Transmitter 5 Display and Configuration Interface
66 Installation and Operations Manual
Display Only Description
Temp Measured temperature in degrees.
Raw Value Un-calibrated resistance measurement value.
Resistance Calibrated Resistance measure value. The Value used to
calculate the actual temperature parameter.
Value1 Parameters used in ratio metric resistance
measurement.
Value2 Parameters used in ratio metric resistance
measurement.
Value3 Parameters used in ratio metric resistance
measurement.
100 Ohm RefRes 24-bit value representing the ratio metric value of a
100-ohm precision reference resistor.
200 Ohm RefRes 24-bit value representing the ratio metric value of a
200-ohm precision reference resistor.
Temp Dis Units Indicates the temperature units that have been set to
display temperature on the LCD. Set in Basic Setup.
Pnt Status RTD PntStatus values:
0x0001 - RTD Temperature Invalid
0x0002 - Resistance is below table value (Under Range -
RTD may be shorted)
0x0004 - Resistance is above table value (Over Range -
RTD may be opened)
0x0008 - RTD is uncalibrated
0x0010 - Hardware Failure
Elapse Time of last update
Pnt Checksum CRC-16 Checksum of point's static configuration
parameters.
Command
Cal. Command Parameter used to activate calibration parameters.
To Next Page
