Varec 2920 - 32-Bit Floating Point Register Map

To Next Page

To Previous Page

2920 Float & Tape Transmitter MODBUSAppendix A — MODBUS Implementation

166 Installation and Operations Manual

32-Bit Floating Point Register Map

3054 Float Temp10 (NMT Prothermo > Elem#11)

3056 Float Temp11 (NMT Prothermo > Elem#12)

3058 Float Temp12 (NMT Prothermo > Elem#13)

3060 Float Temp13 (NMT Prothermo > Elem#14)

3062 Float Temp14 (NMT Prothermo > Elem#15)

3064 Float Temp15 (NMT Prothermo > Elem#16)

3066 Float Average Number

3068 Float Measured Level (NMT Prothermo > Meas. level)

3070 Integer Error code (NMT Prothermo > Cmd Error)

3071 Long Status (NMT Prothermo > Cmd Status)

3073 Integer Diag Code (NMT Prothermo > Diag Code)

3074 Integer Custody Mode

3075 Integer Pnt Status (NMT Prothermo > Pnt Status)

3076 Float HART0 PV (HART Device #1 > PV Value)

3078 Float HART0 SV (HART Device #1 > SV Value)

3080 Integer HART0 Pnt Status (HART Device #1 > Pnt Status)

3081 Float HART1 PV (HART Device #2 > PV Value)

3083 Float HART1 SV (HART Device #2 > SV Value)

3085 Integer HART1 Pnt Status (HART Device #2 > Pnt Status)

3086 Float HART2 PV (HART Device #3 > PV Value)

3088 Float HART2 SV (HART Device #3 > SV Value)

3090 Integer HART2 Pnt Status (HART Device #3 > Pnt Status)

0Level

1 Temp

2RTD Resist

3Reserved

4Reserved

5 Crit Low Level

6 Adv Low Level

7Adv High Level
