2920 Float & Tape Transmitter 5 Display and Configuration Interface
56 Installation and Operations Manual
PIN Codes
PIN codes operate independently and are used to restrict access to configuration or to local
calibration data.
PINs are numerical and the range is between 1 and 9999 inclusively. A PIN code of 0 (zero)
indicates there is no PIN set, the PIN has timed out, or the PIN needs to be entered. The time
out period is about 10 minutes. If the PIN times out, you must re-enter the PIN to continue
working with the 2920.
Config Params Description
Tag The Tag contains 7 bytes of data to identify the
transmitter. The format of the TAG is “LT xxx” where xxx
is the transmitter address.
Decimal Sep. Selects the display of the decimal separator, either a
period (.) or a comma (,).
Format of Zero Selects either a zero or a zero with a slash.
Leading Zeroes Select to display leading zeros in front of the numerical
values.
Scroll Rate The bottom portion of the display can display up to four
data values by scrolling through the items. This
parameter sets (in seconds) how long each item is
displayed.
Backlight Ctrl Sets how long the LCD back light is illuminated after the
last key press. Setting this value to zero, causes the back
light to illuminate continuously.
LCD Contrast Set the contrast on the LCD. The LCD contrast can be
adjusted from the Main Data display by pressing the E
and Plus (+) or the E and Minus (-) to adjust the contrast
up or down respectively.
Display Timeout The time in seconds without a key press before the
Display will returns to the main data display screen.
Order Code The product order code of the encoder assembly can be
added during production.
Product SN The product serial number can be added to the device
during production.
Prim Display This determines data value displayed in the upper
(primary) portion of the LCD. The default in Tank Level.
Sec. Display 1 through 4 These parameters determine which data items is
displayed in the lower (secondary) area of the display.
Display 1 defaults to Tank Temperature. Display 2 to 4
default to no value (undefined).
All Params Lists all Display, Commands, and Config Params in a list.
