2920 Float & Tape Transmitter 10 Configuring HART Devices
118 Installation and Operations Manual
Verifying Communications with a Temperature Device
Do the following to verify communications with a Varec or E+H multi-element temperature
device:
1. Press Enter to open the Main Menu.
2. Press Minus multiple times to select the NMT Prothermo menu.
3. Press Enter to open the NMT Prothermo menu.
4. Press Enter to open the Display Only menu.
5. Press Minus 2 times to locate the Pnt Status.
Verifying Communications with a Level Device
Do the following to verify communications with a Varec or E+H RADAR device:
1. Press Enter to open the Main Menu.
2. Press Minus multiple times to select the FMR Radar menu.
3. Press Enter to open the FMR Radar menu.
4. Press Enter to open the Display Only menu.
5. Press Minus 2 times to locate the Pnt Status.
Verifying Communications with a Generic HART Device
Do the following to verify communications with a generic HART device:
1. Press Enter to open the Main Menu.
2. Press Minus multiple times to select the HART Device menu.
3. Press Enter to open the HART Device menu.
4. Select one of the HART Device #s.
5. Press Enter to open the HART Device # menu.
6. Press Minus 2 times to locate the Pnt Status.
If the Pnt Status is... Then Communications are...
0000 Online
0x01 Offline
If the Pnt Status is... Then Communications are...
0000 Online
0x01 Offline
If the Pnt Status is... Then Communications are...
0000 Online
0x01 Offline
