14 Ordering Information
Varec, Inc. 147
Notes:
1
Ensure a Limit Switch Range option from A to F has been selected.
2
Applies only to Limit Switch option 0. Otherwise select an option from A to F.
3
The number of junction boxes supplied from the factory depends on the Communication,
number of limit switches, Digital Input/Output, Analog Input/Output, and I.S. HART options
selected. Transmitters are supplied with 1-3 junction boxes dependent on the terminal and
wiring requirements.
4
Select the appropriate Display Option depending on the tank gauge used with the 2920
transmitter.
5
Use this option for Electronic Assemblies without housings. (Approvals order code = EA)
6
All communication options come with Ex d HART unless "I.S. HART Inputs/Outputs (HART
Master)" option 1 selected.
Digital Inputs/Digital Outputs
3
1 2 Digital Inputs
2 4 Digital Inputs + 4 Dry Contact Outputs
Analog Inputs/Outputs
3
N None
A Analog Input (4-20 mA)
B Analog Outputs (4-20 mA)
C Analog Input and Outputs (4-20 mA)
HART Inputs/Outputs (HART Master)
3
0 XP/Ex d HART
1 I.S. HART Master I/O, Associated Intrinsically Safe
(XP-AIS/Ex d[i])
Display Options
4
A Forward Facing (standard)
5
B Backward Facing
C Side Facing
N2920 Complete Order Code
N2920
