2920 Float & Tape Transmitter MODBUSAppendix A — MODBUS Implementation
162 Installation and Operations Manual
206 Reserved
208 Reserved
210 Integer AlmStat (Bit Field) (Tank Data > AlmStat)
211 Integer DiagStat (Bit Field) (Tank Data > DiagStat)
212 - 214 Reserved Reserved
215 Coded Level Units (Local Display)
44 - Feet
45 - Meters
47 - Inches
49 - Millimeters
240 - 16ths
241 - Ft-In-16ths
243 - Ft-In-8ths
- Coded Temp Units (Local Display)
33 - F
32 - C
217- 219 Reserved Reserved
220 Coded Level Type (Basic Setup > Enc Direction)
0 - Forward
1 - Reverse
221 Coded Temp Type (Basic Setup > RTD Type)
0 - Pt100
1 - Cu100
2 - Cu90
3 - None
222 - 224 Reserved Reserved
225 Coded Gauge Type (Basic Setup > Gauge Type)
0 - Metric
1 - English
226 Coded Power Control (Basic Setup > Control)
11 - On
12 - Off
227 - 229 Reserved Reserved
230 Float Crit Low Level (MODBUS > CritLowLevel)
232 Float Adv Low Level (MODBUS > AdvLowLevel)
234 Float Adv High Level (MODBUS > AdvHighLevel)
236 Float Crit High Level (MODBUS > CritHighLevel)
238 Float Level Deadband (MODBUS > LDeadband)
240 Float Crit Low Temp (MODBUS > CritLowTemp)
