6.1.4. CEPH Sensor: Bright Calibration
To perform a bright calibration
1. Run the VAKAP.exe file.
Norm C:\VCaptureSW\Acquisition\CEPH\WideCEPHG\Norm
Fast C:\VCaptureSW\Acquisition\CEPH\WideCEPHG\Fast
2. On the dialogbox, click Bright.
3. Check if the median values of the captured images meets the standards below:
※ Filter by calibration point
Bright 4 point 1 point
Filter Cu 1.0T Open
※ Norm Mode Bright standard value: 5 points
Bright Min Max
Median
value
Cal Point 1 200 300
Cal Point 5 1200 ~ 1400
※ Fast Mode Bright standard value: 5 points
Bright Min Max
Median
value
Cal Point 1 200 300
Cal Point 5 600 ~ 800
