3. Select Soft Calib on the Vakcap dialog box.
4. Send the following commands to the command window to set the FPS
Norm
[SPM_CEPH]→[SPM_HSON]→[SPM_CFRQ_0160]→[SPM_COLM_0003]
Fast
[SPM_CEPH]→[SPM_HSON]→[SPM_CFRQ_0313]→[SPM_COLM_0003]
5. Send [SPM_COLM_0003] to the command window to move the colimater to open position.
Command Function
[SPM_CEPH] Ceph mode
[SPM_HSON] Ceph sensor power on
[SPM_COLM_0003]
Collimator open position (without cu filter)
If Collimator is not completely opened, adjust with
[SPM_CDST_XXXX].
[SPM_COLM_0005] Ceph mode position, adjust with [SPM_CAST_####]
[SPM_CFRQ_0160] Sets FPS 160 for the normal mode
[SPM_CFRQ_0313] Sets FPS 313 for the fast mode
6. Click Dark.
