Page 64 of 244
3. Click the Soft Calib tab.
4. Send the following commands to the MCU to set CT sensor and move collimator to an open
position: [SPM_ARCT], [SPM_CSON], [SPM_FIPM_0001], [SPM_FISS_0001],
[SPM_FISM_0001] and [SPM_COLM_0003].
Command Function
[SPM_ARCT] CT mode
[SPM_CSON] CT sensor power on
[SPM_FISS_0001] Normal Mode : 4x4 binning & High gain
[SPM_FIPM_0001] Sensor size setting
[SPM_FISM_0001] Sensor clock (1:External, 0: Internal)
[SPM_COLM_0003]
Collimator Open Position
If Collimator is not completely opened, adjust with
SPM_CDST_XXXX]
5. Click Dark.
