ATTACHMENTS
Attachment 1
TORQUE WRENCH SETTINGS *
Part Thread Tightening torque, N•m (kgf•m)
ENGINE
Main bearing cap bolt å10ı1.25 68.31-84.38 (6.97-8.61)
Oil pump bolt å6 5.10-8.20 (0.52-0.85)
Breather cover retaining stud å8 12.7-20.6 (1.3-2.1)
Breather cover nut å8 12.7-20.6 (1.3-2.1)
Cylinder head bolt å12ı1.25 Refer to chapter «Engine»
Cylinder head bolt å8 31.36-39.1 (3.2-3.99)
Nut, inlet and exhaust pipe securing stud å8 20.87-25.77 (2.13-2.63)
Nut, big end cap bolt å9ı1 43.32-53.51 (4.42-5.46)
Flywheel securing bolt å10ı1.25 60.96-87.42 (6.22-8.92)
Chain tensioner shoe bolt å10ı1.25 41.2-5.0 (4.2-5.2)
Valve cover bolt å6 1.96-4.60 (0.20-0.47)
Camshaft bearing housing retaining nut å8 18.33-22.64 (1.87-2.3)
Oil pump shaft sprocket bolt å10ı1.25 41.2-51.0 (4.2-5.2)
Camshaft sprocket bolt å10ı1.25 41.2-51.0 (4.2-5.2)
Nut, valve adjuster bolt å12ı1.25 43.3-53.5 (4.42-5.46)
Valve adjuster bolt sleeve å18ı.5 83.3-102.9 (8.5-10.5)
Spark plug å14ı1.25 30.67-39 (3.13-3.99)
Coolant pump retaining bolt å8 21.66-26.75 (2.21-2.73)
Nut, water jacket exhaust manifold å8 15.97-22.64 (1.63-2.31)
Crankshaft ratchet å20ı1.5 101.3-125.64 (10.34-12.8)
Alternator bracket bolt å10ı1.25 44.1-64.7 (4.5-6.6)
Nut, alternator mounting plate M10x1.25 28.03-45.27 (2.86-4.62)
Nut, alternator-to-bracket securing bolt M12x1.25 58.3-72.0 (5.95-7.35)
Mounting plate-to-alternator retaining nut å10ı1.25 28.03-45.27 (2.86-4.62)
Retaining nut, engine front mounting bracket å8 10.4-24.2 (1.1-2.5)
Retaining nut, front mounting rubber-to-crosspiece bracket å10ı1.25 27.4-34.0 (2.8-3.46)
Retaining nut, rear engine mounting crosspiece å8 15.0-18.6 (1.53-1.9)
Retaining nut, rear engine mounting / transmission å8 28.3-28.8 (2.38-2.94)
Retaining nut, rear engine mounting / crosspiece å8 15.9-25.7 (1.62-2.62)
CLUTCH
Clutch securing bolt å8 19.1-30.9 (1.95-3.15)
Nut, clutch / brake pedals bolt å12ı1.25 12.7-20.6 (1.3-2.1)
Retaining nut, clutch / brake master cylinders and pedal bracket å8 9.8-15.7 (1.0-1.6)
Nut, clutch hydraulic drive connection pipes å12 24.5-31.4 (2.5-3.2)
Nut, brake hydraulic drive connection pipes å10 14.7-18.6 (1.5-1.9)
