Vaz 21213 - Special Tools for Maintenance and Repair

215
Attachment 2
SPECIAL TOOLS FOR MAINTENANCE AND REPAIR *
Designation Description
ENGINE
Ä.40005 Universal pickers kit
Ä.40026 Removal tool, coolant pump impeller
Ä.50088 Spanner, intake / exhaust pipe nuts
Ä.50113 Allen key, crankcase oil drain plug
Ä.50121 Spanner, crankshaft pulley bolt
Ä.50126 Spanner for checking cylinder head bolt tightening torques (with camshaft in situ)
Ä.60153/R Mandrel for pressing in/out inlet/exhaust valve guide
Ä.60311/R Tool, removal / installation of engine valves
Ä.60312 Removal tool, oil filter
Ä.60326/R Tool to press out ignition distributor / oil pump drive gear bush from the cylinder block
Ä.60330/R Flywheel fixing arm for fitting flywheel to crankshaft
Ä.60333/1/2 Tool to press in/out oil pump drive shaft bushes
Ä.60334 Tool for checking cylinder head tightness
Ä.60430 Installation tool, coolant pump impeller
Ä.86010 Tool for pressing in crankshaft plugs
Ä.90310 Set of reamers, valve guide bore machining
Ä.90353 Reamer for bushes of oil pump drive shaft, ignition distributor and fuel pump
Ä.94003 Core drill (75°), inlet valve seat machining
Ä.94016 Core drill spindle, plug machining
Ä.94016/10 Core drill, crankshaft plug socket machining
Ä.94031 Core drill (20°), exhaust valve seat machining
Ä.94058 Core drill spindle, valve seat machining
Ä.94059 Set of guides, valve seat machining
Ä.94069 Grinding wheel spindle, valve seat machining
Ä.94078 Grinding wheel, exhaust valve seat machining
Ä.94092 Core drill, exhaust valve seat machining
Ä.94100 Grinding wheel, inlet valve seat machining
Ä.94101 Core drill (20°), inlet/exhaust valve seat machining
Ä.95111 Blade for checking camshaft valve lever/cam lobe clearance
02.7812.9500 Socket spanner (13 mm), removal and refitting of starter motor and downpipe
02.7823.9505 Tool, valve removal and installation (can be used in place of Ä.60311/R)
41.7816.4013 Socket spanner (21 mm) for tightening valve lever adjuster bolt guides
41.7853.4010 Installation tool, camshaft cover to engine
41.7853.4011 Installation tool, oil seal + retainer to crankshaft
41.7853.4016 Installation tool, valve guide oil caps
67.7812.9513 Dynamometer for checking fan blower belt tension
67.7812.9514 Spark plug spanner
67.7812.9515 Spanner for checking spark plug tightening torque
67.7812.9519 Socket, spark plug removal/installation
67.7824.9521 Tool for checking wear (extension) of camshaft drive chain
67.7834.9506 Tool for checking fuel pump pushrod protrusion
67.7854.9519 Adjuster bush for fitting normal and oversize pistons of 82 mm dia.
67.8125.9502 Ring gauge (82 mm dia.) for setting inside gauge to zero
67.8151.9505 Gauge for checking fuel level in carburettor
íëé-3/379 Crosspiece, engine removal and installation
Åë-106 Thermostat inspection rig
