Section 1. General Data
Table 1-1
TECHNICAL SPECIFICATION
Features VAZ-21213 VAZ-21214 VAZ-21214-20 VAZ-21215
General
Number of seats 5 5 5 5
Kerb weight, kg 1210 1210 1210 1240
Payload, kg 400 400 400 400
Overall dimensions Fig.1-1
Maximum braking distance at GVW and 80 km/h
on horizontal dry flat asphalt road, not greater, meters:
• with service braking system applied 40 40 40 40
• with emergency system applied (either of two service braking circuits) 90 90 90 90
Maximum speed* in top gear, km/h:
• with driver and passenger 137 137 137 130
• at full load 135 135 135 128
Acceleration time*, 0 to 100 km/h through gear shifting, seconds:
• with driver and passenger 19 19 19 22
• at full load 21 21 21 24
Engine
Model 21213 21214 21214-10 DHW (XUD-9SD)
Type
Four-stroke, Four-stroke, Four-stroke, Four-stroke,
petrol, carburettor petrol, CFI petrol, sequential injection turbo diesel
No of cylinders four in-line four in-line four in-line four in-line
Bore x stroke, mm 82ı80 82ı80 82ı80 83ı88
Capacity, litre 1.69 1.69 1.69 1.905
Compression ratio 9.3:1 9.3:1 9.3:1 21.5:1
Maximum power:
as per GOST 14846 (net), at least, ÍW (h.p.) 58 (78.9) 58 (78.9) 58.5 (79.6) 55 (74.8)
as per ISO 1585, ÍW 58 58 58.5 55
Maximum crankshaft speed at maximum power, rpm 5200 5400 5000 4600
Firing order 1-3-4-2 1-3-4-2 1-3-4-2 1-3-4-2
____________________________________
* Measured using a special procedure
4
