VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Communication Interfaces
46
21. VALVE:OPEN
 Description: Thiscommandinitiatesadispensingcyclewiththeparametercombination
currentlyselected.Rampparametersareindicatedin1/10ms,exceptfor
“Falling“whichisgivenin1/100ms.
 Example: 
  Input: VALVE:OPEN
  Result: Letusassumethatthefollowingconfigurationhas
beenselected:
Rising:10≙1,0ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:15≙0,15ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0,8ms
Thesystemsimplyacceptsthissetand
launchesacorre‐
spondingdispensingcycle.
  Return: OK

22. VALVE:AOPEN
 Description: Thiscommandinitiatesadispensingcyclewiththeparametercombination
currentlyselected.Theparameters“Rising“and“Falling“aredisplayedin
1/100ms,incontrasttotheotherparameterswhicharegivenin1/10ms.
 Example: 
 Input: VALVE:AOPEN
 Result: Letusassumethatthefollowingconfigurationhasbeen
selected:
Rising:55≙0,55ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:15≙0,15ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0,8ms
Thesystemacceptsthissetandlaunches
acorresponding
dispensingcycle.
 Return: OK

23. VALVE:OPEN:<Rising>,<OpenTime>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>
 Description: Thiscommandinitiatesadispensingcyclewiththeparametercombination
currentlyselected. Ramp parameters (i.e.valuesrelating to time) haveto
be specified in 1/10 ms, except for “Falling“ which has to be entered in
1/100ms. Specified values must be integer and positive. If the External
Modeis
desired,insteadofanumericalvalueenter“EXTERNAL”for“Open
Time”.
Itisimportanttoknowthatparameterspreviouslyenteredby
“TRIGGER:SET“arenoterased.
Ontheotherhand,thevaluesenteredby“VALVE:OPEN:<Rising>,<Open
Time>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>”arevalidonly
untiltheendofthedispensingcycle.Ifthecombination
isintendedtobe
usedseveraltimes,thecompletecommandhastoberepeatedatthebe‐
ginningofeachsinglecycle.Insuchasituation,itwouldbemorepractical
tousethe“TRIGGER:SET“commandinstead,sincethecycleinthiscase
canbereactivatedsimplyby“VALVE:OPEN“,as
desired.
