VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Communication Interfaces
45
19. TRIGGER:ASET:<Rising>,<OpenTime>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>
Description: Thisinstructionisusedtomodifycycleparameterswithouttransmittingthe
triggersignal.Thevaluesforbothoftheparameters“Falling”and“Rising”
arespecifiedinstepsof0,01ms.Minimumvaluefor“Falling“:0,01ms
(10%NL),for“Rising“0,01ms(1%NL).Allother
timeparametersareen‐
teredinunitsof0,1ms,asusual.
Specifiedvaluesmustbeintegerandpositive.IftheExternalModeisde‐
sired,insteadofanumericalvalueenter“EXTERNAL”for“OpenTime”.
Thestartofadispensingcyclewiththeselectedparameterconfigurationis
initiatedby
thecommand“VALVE:AOPEN“(instructionno.22,seebelow).
Example:
Input: TRIGGER:ASET:55,10,8,80,20,8
Result: Thefollowingvaluesareassignedtothedispensing
parameters:
Rising:55≙0,55ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:8≙0,08ms
NeedleLift:80%
NumberofPulses:20
Delay:8≙0,08ms
Return: OK
20. TRIGGER:ASET:<Rising>,<OpenTime>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>,1
Description: Asdescribedforinstructionno.18,cycleparameterscanbemodifiedand
savedintheEEPROMofthecontrolunit(Reactiontime:1200ms),without
transmittingatriggercommand.Inthiscasehowever,bothoftheparame‐
ters“Falling”and“Rising”arespecifiedinstepsof0,01ms.Minimum
value
for“Falling“:0,01ms(10%NL),for“Rising“0,01ms(1%NL).Allother
timeparametersareenteredinunitsof0,1ms,asusual.
Specifiedvaluesmustbeintegerandpositive.IftheExternalModeisde‐
sired,insteadofanumericalvalueenter“EXTERNAL”
for“OpenTime”.
Thestartofadispensingcyclewiththeselectedparameterconfigurationis
initiatedbythecommand“VALVE:AOPEN“(instructionno.22,seebelow).
Example:
Input: TRIGGER:ASET:55,10,8,80,20,8,1
Result: Thefollowingvaluesareassigned:
Rising:55≙0,55ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:8≙0,08ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0,08ms
Return: OK
