VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Communication Interfaces
44
Rampparameters(i.e.valuesrelatingtotime)havetobespecifiedin1/10
ms,exceptfor“Falling“whichhastobeenteredin1/100ms.Valueslower
than“1”arenotadmissible.ThereforetheminimumFallingvalueamounts
to0,01ms(10%NL),theminimumRisingvalue0,1ms(1
%NL).
Specifiedvaluesmustbeintegerandpositive.IftheExternalModeisde‐
sired,insteadofanumericalvalue,enter“EXTERNAL”for“OpenTime”.
Thestartofadispensingcyclewiththeselectedparameterconfigurationis
initiatedbythecommand“VALVE:OPEN“(instructionno.21,seebelow).
Example:
Input: TRIGGER:SET:10,10,15,90,20,8
Result: Thisway,thefollowingvaluesareassignedtotheparameters:
Rising:10≙1,0ms(ms=Millisecond)
OpenTime:10≙1,0ms
Falling:15≙0,15ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0,8ms
Return: OK
18. TRIGGER:SET:<Rising>,<OpenTime>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>,1
Description: Withthiscommandcycleparameterscanbemodifiedandsavedinthe
EEPROMofthecontrolunit(Reactiontime:1200ms).Theenteredsetthus
remainsavailableforfutureuse.Atriggercommandhoweverisnot
launched,butcanbeinitiatedbymeansofcommandno.21“VALVE:OPEN“,
sothat
adispensingcyclewiththisparametersetimmediatelystarts.
Rampparameters(i.e.valuesrelatingtotime)havetobespecifiedin
1/10ms,exceptfor“Falling“whichhastobeenteredin1/100ms.Values
lowerthan“1”arenotadmissible.ThereforetheminimumFallingvalue
amountsto0,01ms
(10%NL),theminimumRisingvalue0,1ms(1%NL).
Specifiedvaluesmustbeintegerandpositive.IftheExternalModeisde‐
sired,insteadofanumericalvalue,enter“EXTERNAL”for“OpenTime”.
Example:
Input: TRIGGER:SET:10,10,15,90,20,8,1
Result: Thefollowingvaluesareassignedtotheparameters:
Rising:10≙1,0ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:15≙0,15ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0,8ms
Return: OK
