VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Communication Interfaces
43
Description: Thiscommandisuseful,iftheuserwishestoestimatethedateofthenext
exchangeormaintenance.
Example:
Input: MAINT:STATUS
Result: Currentpercentageofthepresetnumberofcycles(limit).
Return: Maintenance:0%
Nozzle:20%
Tappet:10%
15. TRIGGER:SET:?
Description: TheparametersetpresentinRAMisdisplayed,inthefollowingorder:
Rising,OpenTime,Falling,NeedleLift,NumberofPulses,Delay.
Rampparameters(i.e.valuesrelatingtotime)areindicatedin1/10ms,
exceptfor“Falling“whichisgivenin1/100ms.Ifthevalvecurrentlyis
operated
inExternalMode,thevaluefor“OpenTime“is“EXTERNAL“.In
InfiniteMode,theNumberofPulsesisalways“0”.
Example:
Input: TRIGGER:SET:?
Result: Theuserisinformedaboutthecurrentcycleparameters.
Rising:10≙1.0ms(ms=Milliseconds)
OpenTime:10≙1,0ms
Falling:15≙0.15ms
NeedleLift:90%
NumberofPulses:20
Delay:8≙0.8ms
Return: 10,10,15,90,20,8
16. TRIGGER:ASET:?
Description: Thiscommandcorrespondstoinstructionno.15describedabove.Inthis
casehowever,bothoftheparameters“Rising“and“Falling“aredisplayed
in1/100ms,incontrasttotheotherrampparameterswhicharestillgiven
in1/10ms.
Example:
Input: TRIGGER:ASET:?
Result: Theuserisinformedaboutthecurrentcycleparameters.
Rising:55≙0.55ms(ms=Milliseconds)
OpenTime:10≙1.0ms
Falling:8≙0.08ms
NeedleLift:80%
NumberofPulses:20
Delay:8≙0.8ms
Return: 55,10,8,80,20,8
17. TRIGGER:SET:<Rising>,<OpenTime>,<Falling>,<NeedleLift>,<NumberofPulses>,<Delay>
Description: Thisinstructionisusedtomodifycycleparameters.Iftheuserintendsto
savethisconfigurationintheEEPROM,refertocommandno.18described
below.
