VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Error Messages
63




























5 VALVENOTPRESENTERROR302
 Withsysteminoperation,thecommunicationbetweenvalveandcontrolunitisdisrupted.

ErrorCodeDisplay: VALVENOTPRESENTERROR302

ErrorCodeStatusMenu: VALVENOTPRESENTERROR302

CorrectiveAction:

SwitchOFFcontrolunit,andverifybothoftheconnections
(sensorandactuatorcable).
Defectivecablesmustbeexchanged.
 Otherwise,thevalvemustbereturnedtothemanufacturer.

6 VALVEDEFECTERROR501
 Thevalveduringoperationfails,e.g.duetoadamagedpiezoelectricelement.

ErrorCodeDisplay: VALVEDEFECTERROR501

ErrorCodeStatusMenu: VALVEDEFECTERROR501

CorrectiveAction:
 Thevalvemustbereturnedtothemanufacturer.
7 MDVTEMP.HIGHPLEASEWAIT

Inordertoprotectthepiezoelectricelementfromexcessiveheat,thetemperatureisinter‐
nallymonitoredbyacorrespondingcircuit,automaticallyswitchingOFFthesystemincaseof
need.

Limits:
NL
≤80%=140°C
NL>80%=120°C


ErrorCodeDisplay: MDVTEMP.HIGHPLEASEWAIT

ErrorCodeStatusMenu: TEMPERROR502

CorrectiveAction:

SwitchOFFthesystem.Acertaincoolingphaseisrequired
anyway.MaybethevaluesforNeedleLiftand/orFrequency
parametershavetobelowered,inordertopreventreoccur‐
renceoftheproblem.
 Anothersourceoftheproblemmaybedefectivesensorand
actuatorcableconnections(loosenedplugs,damaged
cables).
Beforeinspection,donotforgettoswitchOFFthecontrol
unit.

8 DATAERRORPRESSENTER

DuringthecheckofRAMdata,aproblemarises.Themessagehastobeacknowledgedby
[enter]key.ThesystemreformatstheEEPROM,replacingcurrentvaluesbythefactoryset‐
tings.

ErrorCodeDisplay: DATAERRORPRESSENTER

ErrorCodeStatusMenu: BADDATA

CorrectiveAction:

Press[enter]key.Thiswayallofthecurrentvaluesare
erasedandreplacedbythefactorysettings.
 Thedesireddispensingparametershavetobereentered.
Duetothisreason,itisrecommendedthatuserskeepsepa‐
ratenotesconcerningthecurrentconfiguration!
Thisallowsforquickreactionin
caseofneed.

