VTK‐VS‐BA‐004e‐B|UserManualMDS3200A | Error Messages
64




























9 INTERNALERROR701

Ahardwarefailureofthevalvecontrolisprobable(e.g.shortcircuitintheconnectionofthe
piezoelectricelement).Thisproblemispossibleduringstartupofthecontrolunitandalso
withsysteminoperation.

ErrorCodeDisplay: INTERNALERROR701

ErrorCodeStatusMenu: DACLOADERROR

CorrectiveAction:

ThecontrolunitmustbeswitchedOFF,atonce.Inspectthe
actuatorcableconnection.Worn,kinkedorcharredcables
mustbeexchanged.
 Thevalvemustbereturnedtothemanufacturer.TheMDC
hastobechecked.

10 EEPROMErrorPressEnter

AcorruptedmemoryareabecomesobviouswhenreadingtheEEPROM.

ErrorCodeDisplay: EEPROMErrorPressEnter

ErrorCodeStatusMenu: EEPROMNOTFORMATED

CorrectiveAction:

Press[enter]key.Thiswayallofthecurrentvaluesare
erasedandreplacedbythefactorysettings.
 Thedesireddispensingparametershavetobereentered.

11 EEPROMErrorPressEnter

TheproblemcanoccurwhenwritingdatatotheEEPROM.

ErrorCodeDisplay: EEPROMErrorPressEnter

ErrorCodeStatusMenu: EEPROMWRITEERROR

CorrectiveAction:

Acknowledgethemessagebypressing[enter].
 Iftheproblemariseswhenmodifyingprogramparameters,
thenewvaluesarenotsavedintheEEPROM.
Afterrestartofthecontrolunit,theformervaluestherefore
stillremaininforce.

12 EEPROMErrorPressEnter

Thestoringprocedureforaset‐up,initiatedbythe[save]key,fails.

ErrorCodeDisplay: EEPROMErrorPressEnter

ErrorCodeStatusMenu: EEPROMSAVEERROR901

CorrectiveAction:

Acknowledgethemessagebypressing[enter].
 Iftheproblemariseswhenmodifyingprogramparameters,
thenewvaluesarenotsavedintheEEPROM.
Afterrestartofthecontrolunit,theformervaluestherefore
stillremaininforce.

13 EEPROMErrorPressEnter

Thisproblemmayariseduringtheretrievalofasetup,by[recall]key.

ErrorCodeDisplay: EEPROMErrorPressEnter

ErrorCodeStatusMenu: EEPROMLOADERROR902

CorrectiveAction:

Themessagehastobeacknowledgedby[enter].
 Repeattheprocedure.Iftheproblempersists,newdata
havetobeenteredtothecorrespondingmemoryposition.

